3PDT Foot Switch Wiring/Breakout PCB

Simplify your pedal-building projects with the 3PDT Wiring Board PCB from Analog Classics. Designed to streamline the wiring process for 3PDT footswitches, this high-quality PCB ensures a clean and organized layout for your DIY guitar effects pedals.

Key Features:

•Effortless Wiring: Eliminates the hassle of point-to-point wiring, reducing build time and potential errors.

•Compact Design: Fits neatly within your pedal enclosure, optimizing space and maintaining a tidy interior.

•Durable Construction: Made from high-quality materials to withstand frequent use and provide long-lasting performance.

•Versatile Compatibility: Compatible with most standard 3PDT footswitches, making it a versatile addition to your DIY toolkit.

•Clear Layout: Well-labeled connections for easy assembly and troubleshooting.

Perfect for both novice and experienced pedal builders, the 3PDT Wiring Board PCB enhances your build efficiency and ensures professional results. Whether you’re crafting a fuzz, overdrive, or any other effect, this PCB is an essential component for a seamless build experience.

Pinout Definitions:

• G – ground
• O – jack out
• I – jack in
• FO – effect out
• FI – effect in
